Smart City Solution

HEINRICH INDIA is a group company of HEINRICH LIMITED that is UK based company Head Office based in London. Heinrich is the smart choice, providing the most comprehensive range of solutions to meet the needs of today's residential, commercial and industrial buildings, Airport, Metro, Hotels, Auditorium, Live Music Performance. Heinrich solutions help customers achieve savings in energy, time and cost, all while enhancing safety.

Heinrich is leading manufacturer of Public address and Voice Alarm and 3D integrated Control System, Heinrich has unrivaled experience in supplying systems and services to major projects spanning all over the world to serve better with high quality product and series.

Solution

Heinrich have a complete solution for Airports, Metro/Railways, Auditoriums, Oil & Gas, Tunnels, Hotels, Hospitals, Corporate, Stadiums, Conferencing Rooms etc.

Use of Pava System at Smart Cities

• Inform Peoples about loitering
• Inform People about Traffic
• Inform People about Alart News/Goverment Updates
• To Inform People and Police if Person Starts running suspiciously
• To Inform if vehicle driving in wrong direction
• To Inform if Vehicle entering in unauthorized area
• To Inform if vehicle driving in Overspeed
• To Inform if Suspicious entering into unrestricted area
• To Inform if vehicle in wrong parking
• To Inform if vehicle in No Parking Zone
• To Inform in any Emergency Situation
• To Communicate with person in emergency Condition
• To Inform in Traffic Congestion
• To Play national songs in National Festival

Product

Component used in Smart Cities in Pava System

Emergency Call Box (ECB) System

As per new life safety standard HEINRICH develop new product which have inbuilt camera, microphone, loudspeaker with IP 66 housing, weather proof, water proof, rust proof and industrial grad. Camera have night vision facility to work in day and night with monitoring facility panels external voice and video pickup surrounding environment noise , the built in HD camera can monitor the surround environment image and in night high quality image and communication on LAN/WAN as assign IP addresses with in the access network intercom can be realized.

Webcast: play regularly real time playback paging in idle the panel can be thought a built in loudspeaker play music or an external voice or recorded broadcast and also can communication like talk back Online upgrade can through network remote upgrade firmware program intercom panel, short circuit input and output, the output DC voltage 90V, the Largest Maximum current 3A linked to the other peripheral equipment alarm linked

Sound Alarm when testing environment volume that persists for more than the preset range to the server or host alarm management , temper alarm when the normal work of the terminal are opened automatically to the server or host alarm management trigger linkage equipment such as alarm bells ring out closed the door etc Full HD digital camera built in full HD, 2 Mega Pixel camera with visible interphone host visible interphone. Built in Digital Audio processor to improve the noise reduction result improve the pickup distance and audio quality.

Compatible with standard SIP protocol can access VOIP phone system independently The Control the host alarm and two-way talk.

Digital Video recording function, when the intercom to record audio and video files stored in the paging microphone uploaded.

IP broadcast emergency alarm system is emergency rapid response system which is based on IP data network and adopt modern communication technology, voice communication technology, computer technology and wireless communication technology; It receives alarm signal by the network alarm host, presets the alarm mode on the server to alarm linkage, which use the networking of user alarm and alarm center to collect, send, receive and process alarm. The system has many advantages, such as: digital transmission, personalization, network management, simple use, powerful function, stable system, zero maintenance.

IP-NAS IP Network Audio System Software

Server of IP network audio system and IP PA system. Support Windows 2000, Windows 2007, Windows 7. All display in English Built-in system set up, system monitor, media player, program timer, system memory functions. Cloud broadcast Mp3 file online, scheduled and matrix at presented time to designated loudspeaker zones. Each equipment’s working status could be monitored and displayed on this software.

Flexible multiple level loudspeaker zone definitions, end user can define loudspeakers into as many as possible zones at the same time. Built-in weekly timer could broadcast pre-recorded voice message, bell, song to selected zones by trigger contact or manually operation. The head equipment to encode analog sources into digital source to be transferred over network.

Support max 5 different sound cards for simultaneously sources collection. One software packet includes administrator and branch server and alarm server. Graphic maps display for visually simple monitoring and operation.

The HEINRICH Audio PM 8 IP Network Paging Micro phone or IP paging console or IP paging station is used to paging over network to remote speaker zones. This paging microphone could be installed to anywhere of the LAN system.

The IP network paging microphone has several paging modes include: zone paging, group paging, all zone paging, two-way intercom, conference system, discussion system & voting system. The IP network paging microphone is built-in a LCD to display program status and its IP address, end -user is accessible to change the IP setting with password. It is built -in a 1W speaker with excellent sound clearance so as to ensure the communication is smooth and clear. This micro phone design is adopted advance d technology to avoid echo noise and to avoid data delay as well.

IP Network & Intercom remote paging microphone – PM8

The HEINRICH Audio PM 8 IP Network Paging Micro phone or IP paging console or IP paging station is used to paging over network to remote speaker zones. This paging microphone could be installed to anywhere of the LAN system.

The IP network paging microphone has several paging modes include: zone paging, group paging, all zone paging, two-way intercom, conference system, discussion system & voting system. The IP network paging microphone is built-in a LCD to display program status and its IP address, end -user is accessible to change the IP settig with password. It is built -in a 1W speaker with excellent sound clearance so as to ensure the communication is smooth and clear. This micro phone design is adopted advanced technology to avoid echo noise and to avoid data delay as well.

IP Based Class-D Amplifier – 120W/240W/500W

The lP PA amplifier range is an ideal network audio solution for multiple speakers middle sized applications. It is used to transmit program from internet to its built-in amplifier then to 100V,70V or low impedance loudspeakers. So, the normal connection way as below: Control port by RJ45 connector to LAN switch and speaker outputs to loudspeakers. The lP network audio adopter is of 19 rack mount design, it is built-in a power amplifier output rated at 120W, 240W to 500W. This LAN network technology also allow this lP network audio adopter with amplifier could be installed anywhere of the LAN system, thus, the cable wiring cost could be saved.

The biggest advantages of the network audio system are: Super distance audio transmission, simultaneous maximum program task and non-dedicated network wiring. Multiple loudspeakers could be directly powered by the built-in power amplifier. It is also designed of local end-user program selection from server by remote control. Local volume also could be adjusted by remote control. Remote control is also could be used to write and change the lP address. Password is needed to access control the equipments to avoid unintentional error. The network audio adopter also is designed with a local microphone input and a local line input, a volume control could be used to adjust the speaker loudness. Three wired volume control is also optional to be connected to this unit. Two reserved communication ports by RJ45 type for future upgrade. One serial communication port only shall be used to write in or change the IP address.

Automatic enter standby mode if no input is detected for 5 minutes and automatically back into service once input is detailed. Two levels of priority output: Voice evacuation system with highest priority and local input with secondary priority over program source. However, the local input and program source priority could be customized. Indicators include output level meter, amplifier power indicator, protection indicator and equipment power indicator. High temp, overload and short circuit amplifier protection.

50W Outdoor Horn Loudspeaker

The MHS50/T is a waterproof horn speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 6” +3” two ways speaker drivers are designed of wide frequency response 90-20kHz, the multiple power taps 3.5W/4.5W/9W/ 12.5W/25W & 50W are helpful for different applications varies from room size and ambient noise surroundings. The ABS enclosure and metal bracket are of gray colour. Easy and secure wall mount installation through the supplied mounting bracket. It is ideal choice for industrial and commercial applicaons in the outdoor area of parking, factory, outdoor application, park, garden, corridor and playground where paging is needed.

System Architecture

• To Inform People and Police if Person Starts running suspiciously.
• To Inform if vehicle driving in wrong direction.
• To Inform if Vehicle entering in unauthorized area.
• To Inform if vehicle driving in Overspeed.
• To Inform if Suspicious entering into unrestricted area.
• To Inform if vehicle in wrong parking.
• To Inform if vehicle in No Parking Zone.
• To Inform in any Emergency Situation.
• To Communicate with person in emergency Condition.
• To Inform in Traffic Congestion.
• To Play national songs in National Festival.

System Installation Terminalogy at Smart Cities

• Each Location has Two 50W Outdoor Music Horn Speaker.
• Loudspeakers Are Connected with IP-Based Amplifier NAP120 with 2 Core Wire.
• NAP120 Is 120W IP-Based (POE) Amplifier Which will be Placed at the Poles to Feed Horn Music Speaker.
• IP-Based Microphone PM8 Will be Placed in the ICCC Building Which Can be Used to Announce All Zones, Individual Zones or Groups of Zones.
• P-Based Microphone Can Be Used as Two-Way Communication with ECB Box Which Will be Placed at Each Locations of Poles.
• All Configuration and Control Will be Through IP-NAS Software.
• ECB Box has Built in 2W speakers And In-Built 25W Class-D Power Amplifier to Connect External Speaker.
• Each ECB Box Can Call to ICCC Building On PM8 Microphone. If line Would be busy it will Generate a Busy tone on Calling Box.
• IP-NAS Software Has a Feature of Creating N-Numbers of Zones. So Expension of Zones Will be Easy to Done.
• ECB Box Has Inbuilt Camera, Microphone, Speaker And Alarm Lamp Which Will be the Best Option For Smart Cities.
• All the Process Can be Configured. Monitored At the Control Centre With the Help of Software Installed PC.
