HEINRICH INDIA is a group company of HEINRICH LIMITED that is UK based company Head Office based in London. Heinrich is the smart choice, providing the most comprehensive range of solutions to meet the needs of today's residential, commercial and industrial buildings, Airport, Metro, Hotels, Auditorium, Live Music Performance. Heinrich solutions help customers achieve savings in energy, time and cost, all while enhancing safety.

Heinrich is leading manufacturer of Public address and Voice Alarm and 3D integrated Control System, Heinrich has unrivaled experience in supplying systems and services to major projects spanning all over the world to serve better with high quality product and series.

Solution

Heinrich have a complete solution for Airports, Metro/Railways, Auditoriums, Oil & Gas, Tunnels, Hotels, Hospitals, Corporate, Stadiums, Conferencing Rooms etc.

System Design

We take full responsibility for the complete system design as per the EN safety standards and customerrequirements. Our Engineering Professionals are well equipped with the knowledgeand are better aware of the todays requirements.

Our Engineering personals work closely with the customer and construction contractors to design a system and offer products that is fully compatible with the site requirements and will not affect the site Infrastructure.

Solution Delivery

We are always excited to work with you, we take full responsibility to provide the best solution for your Project. Our specialized Design and Installation team can help to do this task in much easier, simpler and in an effective way.

We work closely with you until the project is not handover to authority. Our solution is fully complied with the International and Indian Safety Standards. All the Products and solution are EN approved and complies with all applicable standards for the Metro and Railway system. We also offer the system and equipments test in manufacturer Factory to conduct Factory Acceptance Test (FAT) before supply of product at the customer premises to ensure that the products offered are fully complied with the required functionalities and applicable standards.

Product

We offer product from some of best in industry and have a wide experience in product development and technological advancement as per the critical safety requirements. All our R&D Engineers, Technical support and production team are familiar with the complete inside-outside of the products.

Our continue Investment in research and development in building the product range that care and compatible with all applicable norms and standards to comply with all industry.

IP based Audio Router

IP based Audio RouterThe IP based Audio Router is an expandable Pro-Sound quality 1U IP Voice Alarm Audio Router, which for this system will be used together with the Network card. The IP based Audio Router and Network cards provide routing between 12 analogue and 2 IP inputs, and 12 analogue and 2 IP outputs. The device also includes provision for 64 internally stored DVA (digital voice announcement) messages. IP audio can be used to integrate the matrix into larger distributed systems easily connected using industry standard Ethernet. IP Audio transmission is made using PMC (Portable Media Carrier) format for compatibility with IP enabled microphones (MPS-IP). Using Digital Back Bone (DBB), up to four IP based Audio Router routers can be locally linked within a rack location to provide routing from any or all of their inputs to their outputs in a single logical 48 by 48 matrix. The VIPEDIA-12 also integrates seamlessly with amplifier mainframes to provide full system status monitoring and fault reporting as required in EN54-16.

Microphone inputs are connected via RJ45 connections using 0dBu balanced analogue audio and an RS485 serial link. To provide maximum security of operation, two audio inputs, normally assigned to Fireman’s microphones can implement router hardware bypass to ensure continued all-call microphone operation even if the matrix DSP or CPU have failed. A full range of audio processing is available within the IP based Audio Router. DSP based 24 bit / 48kHz audio functions include input dynamics processing, individually adjustable digital output delay of up to 5 seconds and parametric equalization.

Amplifier Mainframe

Amplifier MainframeThe Voice Alarm Amplifier Mainframe is EN54-16 compliant and provides the housing, control, and power supplies for up to ten ASL D Series power amplifier modules in a 2U enclosure.

Two D Series amplifier module types are available, with a maximum power rating of 500W (D500) or 150W (D150). These are lightweight transformerless amplifier modules whose output power is configurable in software from 25W up to their maximum rating. The ability to configure the output power on each module enables opimum assignment of amplifier power within the overall capacity of mainframe and hence a compact system design.

The configurable output power capability of the D500 and D150 amplifier modules enables very flexible use of the mainframe, with reduced mainframe count, less quiescent power requirement, and improved environmental performance compared with traditional amplifier designs. Example applications are:

  • Ten off 150W amplifier = 1 x mainframe and 10 x D150 amplifier module
  • Quad 500W amplifier = 1 x mainframe and 4 x D500 amplifier module
  • Mix-and-match options such as four 50W zones, two 300W zones, and two 500W zone all driven from a single mainframe, including a standby amplifier.
100 to 500 Watt Amplifier Card

100 to 500 Watt Amplifier Card100 to 500 Watt Amplifier card class D transformerless amplifiers provide 100, 70 or 50V audio output for distributed loudspeaker systems. The amplifiers are compatible with the amplifier mainframe and LSZDC dual line surveillance interface module. The maximum output power is user configurable from 25W to 150W and from 25W to 500W. Up to 10 150 and 500 amplifiers modules can be housed within a single amplifier mainframe. The configurable output power capability of the 100 to 500 Watt Amplifier card modules enables very flexible use of the mainframe, with reduced mainframe count, lower quiescent power requirement, and improved environmental performance compared with traditional amplifier designs.

Amplifier Monitoring and Line Surveillance Interface card

Amplifier Monitoring and Line Surveillance Interface CardThe amplifier interface card for use with the 100 to 500 Watt Amplifier card Transformerless Class-D Amplifiers in a Amplifier Mainframe for Voice Alarm and Public Address applications. It enables two circuits (A&B) to be fed from a single amplifier while still maintaining BS5839 Pt 8 compliance.

This interface card provides

  • amplifier health monitoring via subsonic surveillance tone
  • standby switchover
  • loudspeaker line earth leakage monitoring
  • loudspeaker line ‘End of Line’ (EOL) monitoring
Remote I/O Expansion Unit

Remote I/O Expansion UnitThe BMB01 is an input and output control port (I/O) expander for ASL routers. The VIPEDIA-12 Routers are able to support the connection of up to 9 remote BMB01 units, connected by a multi-drop RS485 serial interface. Each BMB01 unit provides the following inputs and outputs to extend the control and interfacing capability of the router:

  • 12 analogue inputs
  • 12 digital (opto-isolated) inputs
  • 12 digital (open collector) outputs

These input and output control ports may be used for functions such as: Program Selection, Volume Control, Fault Input, Routing Control, Routing Reset Input, External Fault Input, and Busy Output.

Wireless Microphone HM600H

Wireless Microphone HM600HHM600H Handheld wireless microphone used for general and emergency announcement in station premises specially on platforms used by security guard to instruct people to stay away from the platform end. The coverage range of wireless microphone is 300 meter enough to cover complete platform.

  • RF frequency: 610-890Mhz
  • Receive channel: 2
  • Channel quantity: 200 channels it can extend several at the same time and the Hand-held channel is all-purpose.
  • Anti-jamming Ability stronger: more than 12 Receivers can be piled up to 400 Receivers can work at the same time
  • PLL Technology: RF stability >+-100Hz
  • Infrared Manual Frequency
  • Auto control quiet/Noise
  • 2 channels Line are Mixed output, XLR is Independent output
  • LCD can show the channel and the Battery capacity
IP Paging Microphone

IP Paging MicrophoneThe IPM comes with both IP connectivity and Hard wired connectivity. It comes with four different forms only PTT, PTT with 10 button, 20, 30, 40, 50 button. IPM is a powerful and flexible paging microphones which can provide live, store-and-forward, and recorded message broadcast into user selected zones, and also provide EN54 compliant emergency functions and all EN54 mandatory indicators and controls. The IPM10/20/30/40/50 units each consist of a IPM sloping desk console with a flexible gooseneck paging microphone, graphic LCD display, and silent operation ‘Touch to Talk’ touch pad PTT button, together with one or more additional zone selection and control button modules.

PA zone selection is provided by the Select buttons or by using the rotary selector and graphic LCD display. There is also a VU bar-graph which displays the microphone signal level. The MPS range can be connected directly to either one or two audio routers using analogue audio and a serial link. There is also an RJ45 Ethernet IP interface with Power over Ethernet for connecton to ASL IP PA/VA systems, and for use with VIPA enabled PC workstations. All interconnecting cabling and the microphone capsule are continuously monitored.

Ambient Noise Sensor

Ambient Noise SensorThe Ambient noise sensor IP65 rated sample and hold Ambient Noise Sensor which is designed to operate under extreme temperatures, from -40°C to +50°C. The ANS will work with the whole range of Public Address and Voice Alarm systems and with VIPA IP-based PA systems.

The purpose of an Ambient Noise Sensor (ANS) system is to adjust the level of public address announcements based on a measure of the ambient noise in the PA zone. This will maintain a set volume of public address audio above the ambient noise, in order to guarantee that the announcement is intelligible, yet at a comfortable level. Public Address or Voice Alarm system is able to support the connection of multiple ANS units. The ANS sensor detects ambient noise using its built-in microphone. The detected signal is weighted with a speech-band response for the best system performance and is then translated to a value of measured ambient noise in dBA. This value is used to proportionally adjust the Public Address or Voice Alarm system output gain for the configured output channel or channels.

Loudspeakers

All Heinrich loudspeaker are EN54 Approved and tested as per BS6259 HEINRICH all speakers support EASE, CATT, ULYSSES models for acoustic studies. This means the acoustic model can be designed to simulate the sound quality and distribution prior to installation All HEINRICH loudspeaker has undergone through testing procedure to ensure that all products compliance with LOW VOLTAGE DIRECTIVE (BS EN 60065, 2003) and EMC (BS EN 61000-6-Part 1/2/3/4).

Ceiling Loudspeaker CMS5/T FDS

Ceiling Loudspeaker CMS5/T FDSThe Heinrich CMS5/T FDS is fire proof ceiling Loudspeaker EN54 Approved and tested as per BS6259 HEINRICH all speakers support EASE, CATT, ULYSSES models for acoustic studies.

The CMS5/T FDS is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 6” speaker driver is designed of wide frequency response 100-18KHz, the multiple power taps 1.5W/3W/6W are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and metal baffle are painted in attractive white colour. Its spring clip clamp makes the easy and secure installation. It is ideal choice for industrial and commercial applications in Railway, Airport, hotel, school, office and factory where background music and paging is needed

Projector Loudspeaker PS20/T

Projector Loudspeaker PS20/TThe PS20-T is a Uni - directional waterproof projection speaker built - in 70v/100v transformer. The 70v/ 100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers.

The built-in two 6” full range speaker drivers are designed of wide frequency response 110-15kHz, the multiple power taps 5W/10W & 20W are helpful for different applications varies from room size and ambient noise surroundings.

The Aluminium enclosure and metal bracket are of white color. Easy and secure wall mount installation through the supplied mounting bracket. It is ideal choice for industrial and commercial applications in the outdoor area of train station, shopping mall, parking area and factory where background music and paging is needed.

Column Loudspeaker OCM 20/T & OCM40/T

Column Loudspeaker OCM 20/T & OCM40/THEINRICH OCM Series column mount loudspeakers are IP56, and compliance with IEC60849 and EN54 approved are robust, weather-resistant construction, yet are surprisingly stylish each model uses 3. 5''full range speakers crossing over to a horn tweeter, it a perfect choice for wall-mounted applications where aesthetic is of prime importance. The Aluminium structure sealed with silicone rubber, gasket, makes the OCM Series water resistant.

Wall Mount Loudspeaker SMS6/T & SMS10/T

Wall Mount Loudspeaker SMS6/T & SMS10/TThe Heinrich Wall Mount Loudspeaker is a built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in two ways speaker driver is designed of wide frequency response 90-20kHz, the multiple three power taps are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and ABS enclosure are of white color. Easy and secure wall mount installation. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

Horn Loudspeaker OHS15/T & OHS30/T

Horn Loudspeaker OHS15/T & OHS30/TThe Heinrich Horn Loudspeaker are waterproof horn speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers.

The built-in horn speaker driver is designed of wide frequency response 300-13kHz, the multiple power taps are helpful for different applications varies from room size and ambient noise surroundings. The ABS enclosure and metal bracket are of white color. Easy and secure wall mount installation through the supplied mounting bracket. It is ideal choice for industrial and commercial applications in the outdoor area of Railway Depot, parking, park, garden, corridor and playground where paging is needed.

Ceiling Loudspeaker for Lift Lobby CMS3/T

Horn Loudspeaker OHS15/T & OHS30/TThe CMS3/T is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 3” speaker driver is designed of wide frequency response 120-20kHz, the multiple power taps 1.5W/3W/6W are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and ABS baffle are painted in attractive RAL9016 white colour. Its spring clamp makes the easy and secure installation. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed. It is an ideal choice for the small area like Lift, Rooms of small dimension etc.

Project Management

We take responsibilities for the complete project Management of the system. Our Management team will look after the complete project from the initial design stage to the end of the project. Throughout the installation and integration process, our project management teams work with you to ensure the project and tasks at hand go as smoothly as possible. Our dedicated team of project managers and CAD technicians will look after all the engineering deliverables that are necessary for the smooth work flow.

In the case of any issues arising during the project our team of managers and Engineers work together to ensure that the work will continue on right track with no or minimum loss of time.

System Installation

Our specialized Installation team are well equipped with mandatory equipments for Installation and follows all the safety standards applicable for the installation work on site under high electrical power or at heights under the supervision of their supervisor.

Our dedicated Installation team are well trained and have expertise for the Installation works like Cabling, Speaker Installation, Display Installation and to build Rack.

Cabling

We are capable to do complete cabling as per the drawings and cable layout schedule designed by our AutoCAD engineer in the station premises with 100% accuracy and without any cable cut or fault.

Speaker and Display Installation

Our Installation team are well trained and equipped with the essential safety guards along with mandatory tools to work at height and fully responsible for the successful installation of display and speakers at height without any fall or damage.

Rack Building

Our specialized team are fully trained and capable in Quality Rack building for the PA system in Metro and Railway system. After the system design and product supply we can build complete Rack equipped with PAVA system equipments with proper ventilation.

Acoustic Study

Our dedicated Acoustic engineers are responsible for complete acoustic study of the station premises using well renowned EASE software for Acoustic calculation and the data provided by the construction contractor about the NRC values of materials used on site.

All the required values for the Acoustic measurement like Direct SPL, Total SPL, RASTI will be measured and a detail simulation report of acoustic study will be submitted during the project design phase.

Commissioning Support

Our trained Engineering professionals in commissioning have a wide experience in providing onsite or remote support after installation of equipments to make it fully functional as per the contractual requirements.

Onsite SPL and STI Testing

We take full responsibility for the complete testing and to achieve required SPL and STI value on site as per the simulation done by our engineers on software with minimum required values as per the standard and contract. Our dedicated Testing team is fully equipped with the standard calibrated testing Equipment for the accurate SPL and STI testing on site.

Onshore and Offshore Training

We offer both onshore and offshore training on our designed system and product. Training will be provided in HEINRICH premises or on site to the maintenance staff.

Our training classes and syllabus designed in such a manner to provide the complete knowledge of system including basic introduction of products to installation and commissioning to the client staff for maintaining the entire system themselves.

Maintenance

Our dedicated Maintenance team can maintain the entire PAVA system throughout the life. We will be responsible for the complete maintenance and troubleshooting of the PAVA equipments, Fault rectification, repairing of damaged equipments and for the replacement of faulty equipments with spares to make the PAVA system fully available 24*7.

Our Maintenance service covers:

  • An initial site survey to ensure our engineers know the complexities and faults of the system.
  • Routine system health checks, both on-site and remote
  • Monthly, Quarterly and Annual reporting
  • Onsite upgrades to long term support firmware.
  • Remote technical support
  • 24hr Telephone support

Product Supply (Logistics)

Our Quality Logistics ensures the on time, safe and secure delivery of equipment hardware without any damage to customer premises or on site. Logistics ensures the proper transportation and supply of goods to the customer.

We are always appreciated for the logistics and received appreciation and positive feedback from customer.

System Interface with Third Party System

Our dedicated software team are experienced in integrating the third party system like PIDS (Passenger Information Display system), Telephone and Radio system, CDRS (Central digital Recording system), Master Clock System, Fault Monitoring System, ATS (Automatic Train supervision System) for the expansion of the System functionalities requirement as per the Standard Telecom specifications of Metro system.
