Oil & Gas Solution

HEINRICH INDIA is a group company of HEINRICH LIMITED that is UK based company Head Office based in London. Heinrich is the smart choice, providing the most comprehensive range of solutions to meet the needs of today's residential, commercial and industrial buildings, Airport, Metro, Hotels, Auditorium, Live Music Performance. Heinrich solutions help customers achieve savings in energy, time and cost, all while enhancing safety.

Heinrich is leading manufacturer of Public address and Voice Alarm and 3D integrated Control System, Heinrich has unrivaled experience in supplying systems and services to major projects spanning all over the world to serve better with high quality product and series.

Solution

Heinrich have a complete solution for Airports, Metro/Railways, Auditoriums, Oil & Gas, Tunnels, Hotels, Hospitals, Corporate, Stadiums, Conferencing Rooms etc.

Use of systems

A public address system can only be used for fire alarm emergency voice notification, under certain circumstances.

The public address system meets the requirements of a fire emergency notification system and those alarms which might be necessary in other building emergencies. PA over IP refers to PA paging and intercom systems that use an Internet Protocol (IP) network, instead of a central amplifier, to distribute the audio signal to paging locations across a building or campus, or anywhere else in the reach of the IP network, including the Internet. Network-attached amplifiers and intercom units are used to provide the communication function. At the transmission end, a computer application transmits a digital audio stream via the local area network, using audio from the computer's sound card inputs or from stored audio recordings. At the receiving end, either specialized intercom modules (sometimes known as IP speakers) receive these network transmissions and reproduce the analog audio signal. These are small, specialized network appliances addressable by an IP address, just like any other computer on the network.

Products

We offer product from some of best in industry and have a wide experience in product development and technological advancement as per the critical safety requirements. All our R&D Engineers, Technical support and production team are familiar with the complete inside-outside of the products.

Emergency Call Box (ECB) System

As per new life safety standard HEINRICH develop new product which have inbuilt camera, microphone, loudspeaker with IP 66 housing, weather proof, water proof, rust proof and industrial grad. Camera have night vision facility to work in day and night with monitoring facility panels external voice and video pickup surrounding environment noise, the built in HD camera can monitor the surround environment image and in night high quality image and communication on LAN/WAN as assign IP addresses with in the access network intercom can be realized.

Webcast: play regularly real time playback paging in idle the panel can be thought a built in loudspeaker play music or an external voice or recorded broadcast and also can communication like talk back Online upgrade can through network remote upgrade firmware program intercom panel, short circuit input and output, the output DC voltage 90V, the Largest Maximum current 3A linked to the other peripheral equipment alarm linked.

Sound Alarm when testing environment volume that persists for more than the preset range to the server or host alarm management, temper alarm when the normal work of the terminal are opened automatically to the server or host alarm management trigger linkage equipment such as alarm bells ring out closed the door etc Full HD digital camera built in full HD, 2 Mega Pixel camera with visible interphone host visible interphone. Built in Digital Audio processor to improve the noise reduction result improve the pickup distance and audio quality.

Compatible with standard SIP protocol can access VOIP phone system independently The Control the host alarm and two-way talk.

Digital Video recording function, when the intercom to record audio and video files stored in the paging microphone uploaded.

IP broadcast emergency alarm system is emergency rapid response system which is based on IP data network and adopt modern communication technology, voice communication technology, computer technology and wireless communication technology; It receives alarm signal by the network alarm host, presets the alarm mode on the server to alarm linkage, which use the networking of user alarm and alarm center to collect, send, receive and process alarm. The system has many advantages, such as : digital transmission, personalization, network management, simple use, powerful function, stable system, zero maintenance.

IP Network Audio System Software (IP-NAS)

Server of IP network audio system and IP PA system. Support Windows 2000, Windows 2007, Windows 7. All display in English Built-in system set up, system monitor, media player, program timer, system memory functions. Cloud broadcast Mp3 file online, scheduled and matrix at presented time to designated loudspeaker zones. Each equipment’s working status could be monitored and displayed on this software.

Flexible multiple level loudspeaker zone definitions, end user can define loudspeakers into as many as possible zones at the same time. Built-in weekly timer could broadcast pre-recorded voice message, bell, song to selected zones by trigger contact or manually operation. The head equipment to encode analog sources into digital source to be transferred over network.

Support max 5 different sound cards for simultaneously sources collection. One software packet includes administrator and branch server and alarm server. Graphic maps display for visually simple monitoring and operation.

IP Network & Intercom remote paging microphone – PM8

The HEINRICH Audio PM 8 IP Network Paging Micro phone or IP paging console or IP paging station is used to paging over network to remote speaker zones. This paging microphone could be installed to anywhere of the LAN system.

The IP network paging microphone has several paging modes include: zone paging, group paging, all zone paging, two-way intercom, conference system, discussion system & voting system. The IP network paging microphone is built-in a LCD to display program status and its IP address, end -user is accessible to change the IP setting with password. It is built -in a 1W speaker with excellent sound clearance so as to ensure the communication is smooth and clear. This micro phone design is adopted advance d technology to avoid echo noise and to avoid data delay as well.

OHS15/T & OHS30/T

HEINRICH Loudspeakers are IP66 and as per EN54 required terminals and outdoor applications used for all required standard IEC60849, BS5839 part 8 OHS series is fully comply as per EASE /CATT/Ulysses. The OHS15/T & OHS30/T is a waterproof horn speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in horn speaker driver is designed of wide frequency response 250-8kHz(OHS15/T) & 300-13kHz(OHS30/T), the multiple power taps 15W & 30W are helpful for different applications varies from room size and ambient noise surroundings. The ABS enclosure and stainless bracket are of white color. Easy and secure wall mount installation through the supplied stainless mounting bracket. It is ideal choice for industrial and commercial applications in the outdoor area of parking, park, garden, corridor and playground where paging is needed.

CMS5/T

The CMS5/T is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 6” speaker driver is designed of wide frequency response 110-15KHz, the multiple power taps 1.5W, 3W & 6W are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and metal baffle are painted in attractive white colour. Its spring clip clamp makes the easy and secure installation. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

CMS5/T FDS

The CMS5/T FDS is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 6” speaker driver is designed of wide frequency response 100-18KHz, the multiple power taps 3W & 6W are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and metal baffle are painted in attractive white colour. Its spring clip clamp makes the easy and secure installation. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

CMS5/DIN

The CMS5/DIN is a fireproof ceiling speaker built-in 70V/100V transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple speakers. The built-in 5, 6 & 8 inch speaker driver is designed of wide frequency response 130-15kHz. This fireproof ceiling speaker is specially designed for fire alarm and voice evacuation system, which is designed and manufactured according to EN54-24 standard. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

CMS-FP15, CMS-FP30 & CMS-FP60

HEINRICH Explosion-proof/Fire Proof PA, EVAC, paging and music horn speaker is approved by EN54 Special design for industrial application like oil field, gas field, coal mine and nuclear power station, industrial applications Suitable for explosion proof, indoor & outdoor and waterproof extremely hostile working environment. Working in explosive gas mixture dangerous atmosphere: 0 zone, 1 zone & 2 zone Working in explosive gas mixture of IIA, IIB & IIC Temperature grade support from T1 to T6 Built -in 100v/70v line transformer. IP66 waterproof and Fire Proof Power output 60W @100V. Steel enclosure and stainless steel bracket in red as per BS6259 part 8 Compliant with explosion-proof EXDII CT6. Approved with fire-proof EN54-24 standards.

SMS6/T

The SMS6/T is a wall mount speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers. The built-in 5”+1” two ways speaker driver is designed of wide frequency response 90-18kHz, the 1.5W/ 3W &6W three power taps are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and ABS enclosure are of white color. Easy and secure wall mount installation. It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

NAP4

The NAP4 is a popular used model for IP/TCP network audio system solution. It is used to transmit program from internet to amplifier and loudspeakers. So the nonanal connection way as below: Control port by RJ45 connector to LAN switch and analogue outputs to amplifiers.

The IP network audio adapter is of 19 rack mount design, so it is usually the biggest advantages of the network audio system are: Super distance audio transmission, simultaneous maximum program task and non-dedicated network wiring installed in the control room together with high watts’ power amplifier for a bigger sized application. This LAN network technology also allow this amplifier could be installed in each floor or local terminal area, thus the cable wiring cost could be saved.

OIP1

The OIP1 is a weatherproof & Explosive-proof two-way communication intercom panel. It is used to have one button press communication with the network paging microphone PM8. It is very reliable industrial two-way communication system for bank, prison, hospital, school, mining plant, transportation centre, airport, metro or subway. In a real application, there will be several network paging microphone PM8 shall use as intercom station for reception desk, information desk, security office, nurse room or logistic centre. Each intercom station network paging microphone will be ID address distinguished by its own IP address, so one intercom station network paging microphone shall be responsible to answer and supervise several IP intercom panel OIP1 Under emergency or information inquiry, the IP intercom panel can press button to call to its pre-designated intercom station microphone can answer or reject the call. if the pre-designated intercom station microphone is long time no answer or busy, the secondary intercom station microphone will be automatically transferred. every ring call is accompanied with warning chime tone and flashing indicator while the intercom station microphone with could directly make announcement or sand pre-recorded messages to the IP intercom panel to warning the potential emergency which may be saw from CCTV system.

The IP intercom panel is built-in a high sensitivity microphone and a 5W full range monitor speaker to ensure voice clearance and loudness. The IP intercom system is built-in dual CPU to ensure minimum sound delay. moreover, special circuit protection is adopted to avoided echo noise within this metal box. The IP intercom panel is built-in a decoder which is used to decode aux and control data into analogate internal amplifier and internal speaker.

This IP intercom panel could be installed in anywhere of non-dedicated network system.so can help to save wiring cost. The IP intercom panel is also with a dry contact output to inter-work with third party low Voltage system like CCTV, door access system and home automation system. Status indicator will be light in different color for paging, intercom and voice alarm system. DC 12V to 24V safe power supplied system. The IP intercom Panel is designed of in-wall or wall mount design of outdoor applications.

HIP1010

The HIP1010 is a weatherproof & explosive-proof two way communication intercom panel. It is used to have one button press communication with the network paging microphone HIP1002. It very reliable industrial two way communication system for bank, prison, hospital, school, mining plant, transportation center, airport, metro or subway. In a real applications, there will be several network paging microphone HIP1002 shall used as intercom station for reception desk, security office, nurse room or logistic center. each intercom station network paging microphone will be ID address distinguished by its own IP address, so one intercom station network paging microphone shall be responsible to answer and supervise several IP intercom panel HIP2010. Under emergency or information inquiry, the IP intercom panel can prees button to call its pre-designed intercom station microphone can answer or reject the call. if the pre-designates intercom station microphone is long time no answer or busy, the secondary intercom station microphone will be automatically transferred. Every ring call is accompained with warning chime tone and flashing indicator. While the intercom station microphone with could direcly make announcement or send pre-recorded messages to the IP intercom panel to warning the potential emergency which may be saw from CCTV system. The IP intercom panel is built-in a high sensitivity microphone and a 5W full rang monitor speaker to ensure voice clearance and loudness. The IP intercom system is built-in a decoder which is used to decode aux and control data into analog to Internal amplifier and internal speaker. This IP intercom panel could be installed in anywhere of non-dedicated network system, so can help to save wiring cost. The IP intercom panel is also with a dry contact output to inter-work with third party low voltage system like CCTV. door access system and home automation system. Status indicator will be light in different color for paging, intercom and voice alarm system. DC 12V to 24V safe power supplied system. The IP intercom panel is desined of in-wall or wall mount design of outdoor applications.

HIP2010

The HIP2010 is a weatherproof & explosive-proof two way communication intercom panel. It is used to have one button press communication with the network paging microphone HIP1002. It very reliable industrial two way communication system for bank, prison, hospital, school, mining plant, transportation center, airport, metro or subway. In a real applications, there will be several network paging microphone HIP1002 shall used as intercom station for reception desk, security once, nurse room or logistic center. each intercom station network paging microphone will be ID address distinguished by its own IP address, so one intercom station network paging microphone shall be responsible to answer and supervise several IP intercom panel HIP1010. Under emergency or information inquiry, the IP intercom panel can prees button to call its pre-designed intercom station microphone can answer or reject the call. if the pre-designates intercom station microphone is long time no answer or busy, the secondary intercom station microphone will be automatically transferred. Every ring call is accompained with warning chime tone indicator. While the intercom station microphone with could direcly make announcement or send pre-recorded messages to the IP intercom panel to warning the potential emergency which may be saw from CCTV system. The IP intercom panel is built-in a high sensitivity microphone and a 5W full rang monitor speaker to ensure voice clearance and loudness. The IP intercom system is built-in a decoder which is used to decode aux and control data into analog to Internal amplifier and internal speaker. This IP intercom panel could be installed in anywhere of non-dedicated network system, so can help to save wiring cost. The IP intercom panel is also with a dry contact output to inter-work with third party low voltage system like CCTV. door access system and home automation system. Status indicator will be light in different color for paging, intercom and voice alarm system. DC 12V to 24V safe power supplied system. The IP intercom panel is desined of in-wall or wall mount design of outdoor applications.

IMP-2307

The IMP-2307 is an indoor two way communication intercom panel, it is full duplex system, so it can talk to another IMP-2307 and it also can talk to PM8 duty microphone. It is used to have communication with the network paging microphone PM8 or another IMP-2307 it is very reliable industrial two way communication system for bank, prison, hospital, school, mining plant, transportation center, airport, metro or subway in a real applications, there will be several network paging microphone PM8 shall used as duty service for reception desk, security office, nurse room or logistic center.

Each duty network paging microphone will be ID address distinguished by its own IP address, so one duty network paging microphone shall be responsible to answer and supervise several IP intercom panel IMP-2307. under emergency or information inquiry, the IP intercom panel can press button to call to its pre-designated duty microphone, the duty microphone can answer or reject the call. If the pre-designated duty microphone is long time no answer or busy, the secondary duty microphone will be automatically transferred. Every ring call is accompanied with warning chime tone and flashing indicator. while the duty microphone with cold directly make announcement or send pre-reccorded messages to the IP intercom panel to warning the potential emergency which may be saw from CCTV system. The IP intercom panel is built-in a high sensitivity microphone and a stero 10W + 10W amplifier to ensure voice clearance and loudness. The intercom panel is a full duplex network audio adapter, which could make announcement or broadcast voice clearance and loudness. It is designed of a 2.8 inch LCD to display its IP address and working status, friendly end user interactive network audio solution system. The IP Intercom system is built-in dual CPU to ensure minimum sound delsy. Moreover, special circuit protection is adopted to avoid echo noice within this metal box. The IP intercom panel is built-in a decoder which is used to decode aux and control data into analog to internal amplifier and external speaker. This IP intercom Panel could be installed in anywhere of non-dedicated network system, so can help to save wiring cost. The IP Intercom panel is also design of a local aux input and also aux output which could be used to connect with an external amplifier. The IP intercom panel is designed of in-wall or wall mount design of indoor applications.

DPA Series

The DPA range digital Class-D power amplifier is of switching power technology, which features of minimum power consumption and much higher efficiency up to 95% moreover it help to save installation rack space, generate less heat so as to extend its performance life span as a result. Automatic standby enable after no detection of signal input for one minute, immediately wake up at sight of any input. DPA Series is available in 120W/125W/240W/500W with single channel, Dual and four channels.
